Red Mulberry Search and Rescue: Preserving Genetic Diversity for the Future of Sustainable Agroforestry

Final report for FNC22-1338

Project Type: Farmer/Rancher
Funds awarded in 2022: $19,437.00
Projected End Date: 06/15/2025
Grant Recipient: Solid Ground Farm
Region: North Central
State: Ohio
Project Coordinator:
Weston Lombard
Solid Ground Farm
Expand All

Project Information

Description of operation:

Solid Ground Farm is a 60 acre diversified small farm and education center with a focus on agroforestry and homescale livestock. We are particularly interested in improved native and naturalized fruit and nut crops to feed people and livestock and have several orchards and forest gardens of various sizes and ages producing everything from Chinese chestnuts to mulberries. The farm is 12 years old and also houses a summer camp, a nature-based elementary school, and a community garden.

Summary:

Our native red mulberry, Morus rubra—a fruit-producing tree with delicious, nutritious, complex-flavored fruit, high production potential, innate pest/disease resistance, and rapidly growing commercial and home production interest—is slowly fading from its native range due to the rapid spread of the invasive Morus albaMorus alba was imported in the 1600s and planted by the millions across the eastern seaboard in a failed attempt to create a domestic silk industry. Trees quickly escaped from these orchards and have since naturalized across the country.  These invasive trees release large amounts of wind-dispersed pollen that readily pollinate the native trees, producing hybrid offspring that are steadily and irrevocably replacing pure Morus rubra

In order to address this slow-motion extinction by hybrid replacement, we propose to find, propagate, and establish preserves and breeding orchards of high-quality, fruit-producing Morus rubra specimens with commercial potential. By holding a national mulberry Search and Rescue Contest, we plan to crowdsource the best Morus rubra trees growing wild, in orchards, and nursery rows across the country. Entries will be genetically tested, rated for potential as commercial cultivars, and the winning trees named and made available to farmers, nurseries, researchers, and fruit enthusiasts throughout the North Central region.

Through this project we created a Morus rubra identification guide and helped the public to identify and share samples from mulberry trees suspected of being pure Morus rubra. We received over 100 fresh leaf samples from around the country. Samples were sent to the Ohio University Genomics Facility where they were frozen and then the DNA extracted. Samples were then used to begin constructing a Morus rubra genome by researchers at the Los Alamos National Laboratory (this process is ongoing due to the complexity of the genome). This information was then cross-referenced with the existing Morus alba genome and each individual sample was analyzed and results compiled.  Because of the complexity of the project and the lack of an existing complete rubra genome, the results are not necessarily indicative of complete purity of species, but do show with a high degree of accuracy whether a sample is rubra, alba, or a hybrid, as well a good inidcation of the degree of possible hybridization.  Results for instance indicate that Illinois Everbearing, a popular mulberry considered a hybrid, has mostly rubra characteristics but does contain a trace of alba.  For the results of the study, we classified specimens by the closest obvious fit and marked those with mainly rubra characteristics as "Rubra" and those with obvious high alba influence as "Hybrids". A closer look at the numbers, however, can tell us the degree of hybridization of each specimen.

While imperfect, the results do indicate that many pure or nearly pure rubra trees do still exist in different regions across the country, and while further analysis will be needed to determine complete purity, we are moving in the right direction and have found specimens with good fruit production that can be considered native and are definitely worth growing as food producing trees.

Project Objectives:
  1. Hold a contest to find productive Morus rubra specimens with commercial potential and perform genetic testing of advertised "Morus rubra" cultivars (often mislabeled Morus alba trees that have red fruit) to establish verified native sources.
  2. Name and release several new Morus rubra cultivars suitable for orchard production.
  3. Propagate and establish a preserve and breeding orchard in order to provide verified native mulberry plant material to nurseries, farmers, conservation workers, researchers, and landowners throughout the North Central region.
  4. Promote the value, usefulness, and profitability of growing native mulberry trees through field days, website and social media promotions, and a scholarly journal.

Cooperators

Click linked name(s) to expand/collapse or show everyone's info

Research

Materials and methods:

The goal of this project is to identify superior Morus rubra specimens suitable for fruit production. Then genetically test them to establish pure native sources of mulberry to share with the general public.  To achieve this we have taken a crowdsourcing approach and created a Facebook event promoting a Mulberry Search and Rescue Contest. We are offering free genetic testing to participants and help developing connections with nurseries and other buyers of mulberry cuttings and scionwood for those interested.  We will then buy propagation materials from the test entrants and clone the trees to start a research/demonstration/breeding orchard.

The contest has gone well and has been promoted heavily on various interest groups and online forums.  We found some great potential trees, but have been delayed in the testing process.  We based our initial plan on a Canadian study that established genetic markers for wild Morus rubra trees up north. However, upon deeper review of the study methods, our geneticist consultant suggested that the number of markers and the type of test used (RAPD) were insufficient for our goals of establishing definitive purity of our source material.  As a result, we have spent considerable time researching alternative testing plans and have come up with a new plan utilizing GBS testing that will provide more accuracy. This project is particularly challenging because, unlike more common trees, the genome for Morus rubra has not yet been mapped to provide a basis for easy comparison, so we are essentially building the map as we go.

This revamping is resulting in a delay and relaunch of the contest.

After relaunch we now have 100 promising samples from around the country and have chosen a half dozen of them that appear most likely to be pure Morus rubra specimens for our first round of testing. These samples will be tested and reviewed to create a reference genome and establish markers for identifying future rubra specimens.  After this is established, the remaining samples will be compared to this reference and cross-referenced against the Morus alba genome to establish if samples are hybrids or pure rubra specimens.  This process is new and has taken time to establish, resulting in a further delay of our results. We have just been approved for an 11-month extension to finish the project.

The project has expanded to include contributions from the Ohio University Genomics Lab, Nigel Daniels,  Los Alamos National Laboratory (LANL), and Jonathan Gesualdi of The Naked Oak Tree Farm, and additional information will be added to this report as it becomes available.   We have now completed the first round of testing and ou can read about the methodology and technical results from Nigel Daniels here.

In addition to the genetics test performed, we have partnered with, Jonathan Gesualdi, who has developed a morphological assessment and key using microscpopic viewing of trichome density and petiole groove/vascular bundle orientation to determine mulberry species.  Jonathan is currently cross checking our genetic work to validate his process and refine our results.  Information from his finding will be added to this report as it becomes available as well as on his website at: https://thenakedoaktreefarm.com/red-mulberry

abaxial view of sample #58 leaf where we are establishing a new trichome density range to differentiate hybrids vs pure rubra.

From Jonathan: The above photo is of the abaxial view of sample #58 leaf where we are establishing a new trichome density range to differentiate hybrids vs pure rubra. This is based on the original paper Asymmetrical introgression by K. S. BURGESS, et.al. They proved that trichome density is a statistically significant trait that can be used to differentiate hybrids vs pure rubra. However, their mythology was unclear to replicate their observations. After conferring with the authors we decided that a different method was necessary what would be easier to replicate by anyone with a microscope and will be fully detailed in a key with instructions we would like to distribute to those seeking to tell pure rubra from hybrids visually.

Mulberry Petiole morphology
This image focuses on the petiole morphology. This is an existing trait already included in the "More on Muddled Mulberries" paper that partners are performing on the sample set to confirm its accuracy and perhaps expand on the morphological differences in the vascular bundles.


Petiole/leaf junction morphology

This image is one that Paul and Julian are using in their soon to be published follow-up paper with discussion specifically on the petiole/leaf junction morphology and other expanded morphological assessments.

Photo credit: Paul Adanick

Jonathan is still accepting samples to test and can be reached at: Jonathan@TheNakedOakTreeFarm.com

Creating a complete Morus rubra genome proved to be outside the scope of this project, however, the momentum has been created and we hope to have more information to share in the coming years.

Research results and discussion:

Genetic testing has revealed the likely existence of many pure or nearly pure Morus rubra trees across the United States, and while based on current information, we cannot yet say with 100% accuracy which samples are entirely native, we have a good sense and are happy to share the results below.  As more information becomes available and the genome is fully assembled, testing will become more and more accurate.

The results of our research can be viewed below. We are still assessing who from this list is interested in sharing scionwood from their trees and will soon add a document with a list of potential sources of cuttings for those interested in purchasing Morus rubra grafting material.

Results (from report by Nigel Daniels)
Read full report with methodologies here.

Ct values for each sample were compared for differences between detection of the species-specific genomic regions labeled Rub232, Rub236, and Alb233. Differences of ~10 cycles between specific-region Ct values were used as an indication of whether a sample was likely M. rubra, M. alba, or a hybrid. A lower Ct value indicates a higher quantity of genomic DNA containing the region targeted by that primer pair present in the reaction. Thus, values of ~18-21 for the Rub regions and >~28 for the Alb region indicate a likely M.rubra species identification. Values opposite to this indicate likely M.alba, whereas ~18-21 values for any combination of Rub and Alb regions indicate a likely hybrid.

Table 2. Summary of Quantitative PCR Threshold Cycle (Ct) values for the species-specific genomic regions Rub232, Rub236, and Alb233 produced from Mulberry leaf genomic DNA samples. “Indicated Species” denotes the species of the sample based on the regions tested but does not absolutely guarantee the absence of DNA from other species in untested regions.


Sample ID Submitted by: Rubra232 Ct Rubra236 Ct Alba233 Ct Indicated Species
1 Jamie Belcourt, Conway AR 19.02 18.99 28.37 Rubra
2 Mark Travis, Gainesville FL, Williston 24.48 24 34.35 Mostly Rubra
3 Mark Travis, Gainesville FL, Katy 20.56 20.99 36.5 Rubra
4 Mark Travis, Gainesville FL, Barr Hammock 19.28 19.17 29.85 Rubra
5 Kathy Jacobson, Stewart OH, Gate 21.98 21.95 21.78 Hybrid
6 Kathy Jacobson, Stewart OH Stem at base of big tree 20.61 20.15 20.15 Hybrid
7 Peaceful Heritage Nursery, Stanford KY, Queen Luscious 19.42 20.02 19.94 Hybrid
8 Peaceful Heritage Nursery, Stanford KY 40484, Varaha 20.45 19.91 27.44 Mostly Rubra
9 Dan Greenberg, Matthews NC, 19.84 19.32 28.12 Rubra
10 Dan Greenberg, Matthews NC 19.98 19.44 31.97 Rubra
11 Michael & Keary Mariannino, Charlotte Court House VA 24.26 24.27 37.52 Rubra
12
Duplicate sample

13 Jay McGrath, Dayton OH 20.17 20.51 25.84 Hybrid
14 L. Eubank, Elizabethtown IN 20.84 20.11 20.15 Hybrid
15 Elizabeth Reznar, Lebanon OH 21.85 21.61 32.48 Mostly Rubra
16 Lydia Nichols, Chesterfield VA 21.73 21.67 23.87 Hybrid
17 David Snyder, Johnson County, IN 19.1 19.03 30.02 Rubra
18 Hunter None 35.73 19.94 Alba
19 Leslie Wade "Hem & Holler", Ellijay GA 18.83 18.71 30.47 Rubra
20 Leslie Wade "Ever Wilder Farm", Ellijay GA 18.92 18.81 30.08 Rubra
21 Darren, Locust Grove E 18.82 18.82 29.72 Rubra
22 Darren, Locust Grove W 19.1 18.94 29.68 Rubra
23 Darren, Black Bramble ♂&♀ 19.52 19.06 31.31 Rubra
24 Darren, Open Field 18.41 17.77 28.36 Mostly Rubra
25 Mike Hater 1 None None None Unknown
26 Mike Hater 2 18.91 18.42 29.25 Rubra
27 Katarina Midelfort, Purplewood 1 18.87 18.58 29.8 Rubra
28 Katarina Midelfort, Purplewood 2
Duplicate sample

29 Katarina Midelfort, Stockdell 1 18.73 18.3 29.38 Rubra
30 Katarina Midelfort, Stockdell 2
Duplicate sample

31 James Arnold, Leland NC, Sample 1 18.55 18.64 30.69 Rubra
32 James Arnold, Leland NC, Sample 2 19.08 19.04 31.11 Rubra
33 Caryl Orr, Cottendale AL, Red Mulberry, 18.37 18.48 30.26 Rubra
34 Weston Lombard, Woodward Rubra 20.11 20.02 19.89 Hybrid
35 Weston Lombard, Liars corner Rubra 18.22 18.2 29.55 Rubra
36 Weston Lombard, Tartarica Alba #1 18.3 33.33 17.03 Hybrid
37 Weston Lombard, Tartarica Alba #2 32.52 33.51 19.33 Alba
38 Weston Lombard, Alba #3 Seedling 32.99 33.89 20.93 Alba
39 Weston Lombard, Alba #4 Seedling None 30.2 17.38 Alba
40 Weston Lombard, Silkhope Rubraxalba 18.99 19.1 18.76 Hybrid
41 Weston Lombard, Maulticulis 18.19 29.07 18.53 Hybrid
42 Weston Lombard, Shelli 33.89 31.21 18.86 Alba
43 Weston Lombard, nursery bought rubra seedling 19.91 32.96 19.28 Hybrid
44 Weston Lombard, Rubra 18.38 17.92 28.59 Mostly Rubra
45 Weston Lombard, IE 18.37 18.13 25.79 Mostly Rubra
46 Weston Lombard, Kip Parker 19.61 18.98 19.19 Hybrid
47 Weston Lombard, World's Best 18.68 32.71 17.9 Hybrid
48 Weston Lombard, Oscar Rubrax Alba 19.5 30.19 18.1 Hybrid
49 Weston Lombard, SGF Alba 33.09 31.83 18.98 Alba
50 Weston Lombard, Terrace Alba None 33.66 22.28 Alba
51 Weston Lombard, Terrace Rubra 20.09 19.9 27.29 Mostly Rubra
52 Weston Lombard, nursery Rubra seedling 33.14 30.55 19.26 Alba
53 Weston Lombard, Rubra seedling 33.7 33.87 18.13 Alba
54 Weston Lombard, Ukranian giant Alba 33.17 32.25 18.36 Alba
55 Weston Lombard, nursery Seedling 18.5 28.89 18.26 Hybrid
56 Vicki Shaub, Nashville TN 37211 19.24 18.77 30.52 Rubra
57 Vicki Shaub, Nashville TN 37211
Duplicate sample

58 Vicki Shaub, Nashville TN 37211
Duplicate sample

59 Benny Becker, Beckley WV, "Gorgeous" 19.44 18.99 19.14 Hybrid
60 Varaha, Peaceful Heritage Nursery 19.6 19.18 27.08 Mostly Rubra
61 Spillway, Lucky Pittman 19.17 18.07 29.57 Rubra
62 Cindy Redding, Mulberry Apiary 36.05 32.82 19.08 Alba
63 P Pitre Byron, Gray LA, Mature tree 19.49 18.86 35.6 Rubra
64 P Pitre Byron, Gray LA, Mature tree
Duplicate sample

65 P Pitre Byron, Gray LA , Sapling #1 19.58 19.61 31.55 Rubra
66 P Pitre Byron, Gray LA, Sapling #2 33.6 21.84 20.41 Hybrid
67 Elena Obradovich, Slemp KY 30+ yrs old, fruit producer 18.8 18.53 29.92 Rubra
68 James Garlanger, Oviedo FL, Bruce's Red 19.68 19.42 30.49 Rubra
69 James Garlanger, Oviedo FL, Rootstock seedling 20.58 32.86 19.89 Hybrid
70 James Garlanger, Oviedo FL, Oviedo H 19.33 19.23 31.04 Rubra
71 James Garlanger, Oviedo FL, Oviedo #1 19.56 19.39 30.93 Rubra
72 James Garlanger, Oviedo FL, Oviedo #2 20.89 20.39 32 Rubra
73 James Garlanger, Oviedo FL, Farm #1 19.73 19.22 31.33 Rubra
74 James Garlanger, Oviedo FL, Farm #2 18.79 18.43 28.94 Rubra
75 James Garlanger, Oviedo FL, Farm #3 19.69 19.14 30.91 Rubra
76 James Garlanger, Oviedo FL, Farm #4 20.34 19.7 31.53 Rubra
77 Marco Contino, Raleigh NC, Adeline's Mulberry 19.65 19.51 31.66 Rubra
78 David Snyder, Ortet, Smith Valley Mulberry, 20.27 20.38 29.57 Rubra
79 Zaros #1 18.52 18.49 30.84 Rubra
80 Zaros #2 18.77 18.7 30.66 Rubra
81 Zaros #3 19.25 18.91 31.19 Rubra
82 Zaros #4 18.85 18.77 29.68 Rubra
83 Zaros #5 18.52 18.18 30.25 Rubra
84 Chen Chang, Lebanon G, Miss Kim 19.89 32.95 18.88 Hybrid
85 Chen Chang, Lebanon GA, Robert 20.72 31.06 19.51 Hybrid
86 Chen Chang,, Lebanon GA , Greenwich 19.97 19.45 22.6 Hybrid
87 Chen Chang, Lebanon GA, Lucile 19.18 18.54 21.96 Hybrid
88 LLP H. Hopkinsville KY, Harmony Grove (East), ♂ M.rubra? 20.7 20.22 20.52 Hybrid
89 LLP H Hopkinsville KY Island Cove, Old ♀ M.rubra 19.01 18.87 30.74 Rubra
90 LLP H, Hopkinsville KY Workman, ♂ M.rubra 18.27 18.45 30.62 Rubra
91 LLP H Hopkinsville KY , Roberts Farm #6, ♀ M.rubra 18.92 18.92 31.18 Rubra
92 LLP H Hopkinsville KY , Roberts Mailbox, ♀ M.rubra 19.2 19.2 31.94 Rubra
93 LLP H Hopkinsville KY Harmony Grove (West), ♀ M.rubra 18.98 18.93 31.49 Rubra
94 LLP H, Hopkinsville KY 42240, Spillway, ♀ M.rubra 20.35 19.28 31.58 Rubra
95 Miles George, Aberdeen NC 21.35 30.7 20.94 Hybrid
96 David Barker, Scott LA 19.66 19.44 33.1 Rubra
97 Lara Plumb, Evansville AR , Tree #1 19.3 18.81 31.68 Rubra
98 Lara Plumb, Evansville AR , Tree #2 20.62 19.2 32.65 Rubra
99 Lara Plumb, Evansville AR , Tree #3 19.8 19.42 33.05 Rubra
100 Robert Gustafson, Machipongo VA #01, Male tree by Bay 20.19 19.59 33.29 Rubra
101 Robert Gustafson, Machipongo VA #02, Female tree, Large sharon's woods 19.16 19 29.58 Rubra
102 Robert Gustafson, Machipongo VA #03, Female, Small sharon's woods 19.07 19.08 30.63 Rubra


Discussion:
As expected the limited seedling trees that we acquired from nurseries advertised as Morus rubra ended up being hybrids or albas. This is not to say that native red mulberry cannot be found at domestic nurseries, but highlights the need for more education when collecting seed and a reminder that red fruit does not indicate a red mulberry tree.  Given a visual guide and with experience of mulberries, many amateur fruit explorers were able to find native mulberries growing throughout the country, indicating that many more likely exist to be discovered and shared.  Please find resources at https://thenakedoaktreefarm.com/red-mulberry for identifying trees yourself using a microscope or for fee-for-service testing of your collected specimens.

Please check back periodically to this report for updates on where to source red mulberry seed or cuttings, or email westonlombard@gmail.com until a resource becomes available.

Thank you to everyone who contributed to this exciting project.  Looking forward to next steps.

Update re: Objectives #2 and #3:
Since the test results just came in, I wasn't able to create a reference guide for red mulberry cultivars yet, but am reaching out to people to see if they want their specimens and contact info listed and will eventually share a resource guide to help people access trees and cuttings.  Might be a few months though.

As for the orchard preserves, we had planned to plant at Hocking College and at UVA Wise where there are not a bunch of established white mulberries already, but since they both dropped out of the grant, we had to plant at my farm.  Instead of a pure rubra orchard, I have had to plant rubra's into my existing orchards wherever I could fit them and it still serves the purpose of a preserve, but isn't going to be able to work as a breeding area for pure morus rubra, because of how many alba and hybrids I have growing already.  Still it is an area where people can see different specimens, sample diverse mulberry flavors, and collect scionwood.
Participation Summary
60 Farmers participating in research

Educational & Outreach Activities

3 Curricula, factsheets or educational tools

Participation Summary:

168 Farmers participated
5 Ag professionals participated
Education/outreach description:

In order to spread the word about our project and the Mulberry Search and Rescue Contest to land owners, farmers, and fruit enthusiasts, we first networked and consulted with other mulberry enthusiasts in order to create Contest Instructions and a resource list of Morus Rubra Identification Guides. Once this was in place we launched a Facebook Event with an easily shareable link that we could all distribute to our networks. This event link and the contest instructions were then shared on fruit growing forums, Facebook interest groups (primarily NAFEX and my own Growing Mulberry in Temperate Climates pages, and other targeted interest groups), and in email chains. The Facebook event and interest group pages were then regularly updated with videos about mulberry harvests, taste comparisons, and photos of fruit size.  Because a really comprehensive identification video comparing the common mulberry species and hybrids wasn't accessible, we also created the most in-depth identification video available online.

We have now hosted a second round of the contest and collected an additional 50 samples.  We are still working to complete the testing and share the results through similar avenues as well as direct messages to nurseries that may be interested in growing the newly released cultivars.

Learning Outcomes

5 Farmers reported changes in knowledge, attitudes, skills and/or awareness as a result of their participation
Lessons Learned:

We did confirm that thanks to the internet and the abundance of interest groups on specific topics like growing mulberries, that crowd-sourcing is a great way to find new trees worthy of propagation and sharing. This method has been used since at least the 1900's when people like John Hershey would put out ads in local papers requesting superior nuts and fruits be sent to him for evaluation. Thanks to the internet, this process is now much easier and cost effective and superior cultivars of any wild or domestic crop could be discovered and shared in such a manner.

The greatest problem we have faced is unique to this species and to figuring out the perfect and yet affordable genetic testing protocol for Morus rubra.  Consulting with more geneticists prior to launch definitely would have helped for a smoother roll out of the project.

Project Outcomes

15 Farmers changed or adopted a practice
1 Grant received that built upon this project
5 New working collaborations
