Establishing a Cool Season Legume Grass Finishing Pasture

Final report for FW22-398

Project Type: Farmer/Rancher
Funds awarded in 2022: $8,992.00
Projected End Date: 04/30/2025
Grant Recipient: Browns Meadow Farm
Region: Western
State: Montana
Principal Investigator:
Ronald Wade
Browns Meadow Farm
Expand All

Project Information

Summary:
  • A major challenge for an organic grass-fed/finished operation is quality finishing pasture.  Such a pasture must be better quality than one that supports a cow-calf herd.  Historically, organic grass-fed/finished operations haven't been investigated; one (SW17-046) assessed dairy cattle performance.  Our research question asks if a legume-grass (various legumes) pasture can be established under organic conditions (no herbicide, no commercial fertilizer), at three environmentally different locations, that produces a density comparable to nearby existing grass pastures.
  • We propose seeding acreages of approximately 40, 10, and 10 acres to sainfoin-grasses,  sainfoin-orchardgrass, and both sainfoin-orchardgrass and birdsfoot trefoil-orchardgrass.  The first acreage has three sainfoin varieties mixed (Eski, Remont, Shoshone) nearby, the second supported Eski in the past, while the third is slightly acidic.  If these pastures produce a density comparable to existing grass pastures, their establishment is beneficial to the environment and pasture finishing due to the presence of legumes (https://doi.org/10.1093/jas/skaa278.139).
  • We will determine if the legume-grass seedings can be established at comparable densities as nearby existing grass pastures, or not.  If they can, there are two major benefits.  First, the legume contributes benefits to the soil and forage that are different from those of grass.  Second, sainfoin and birdsfoot trefoil do not cause bloat in cattle, which makes them very useful for grazing in an organic grass-fed/finishing operation.  These benefits are important for sustainability, the first because of its environmental contributions and the second because of its economic importance.
  • Results will be disseminated to local networks by ranch tours and presentation.

NO MODIFICATIONS.















Project Objectives:
  1. At two locations, can a sainfoin-grass pasture be established that is generally comparable in density to a nearby existing grass pasture?
  2. At a third location, can a sainfoin-grass pasture and a birdsfoot trefoil-grass pasture be established that is generally comparable in density to a nearby existing grass pasture?
  3.  Disseminate the results from the above objectives to local networks.
Timeline:

WSARE Timeline

A no cost extension of one year was requested and approved.

Cooperators

Click linked name(s) to expand/collapse or show everyone's info
  • Jess Alger - Producer
  • Jack Stivers - Technical Advisor
  • Lisa Wade - Producer
  • Ryan Wade - Producer

Research

Materials and methods:

The only goal of this proposal is to determine if it is possible to establish a cool season legume grass finishing pasture, at comparable density levels as nearby grass pastures, at three environmentally different locations: Stanford, Marion, and Kila.  We break this goal into three objectives: planting such a pasture to various legume grass mixes, sampling the planted ground at three different times (early summer and early fall, 2022, and early summer, 2023) to obtain quantitative results, and presenting our results.

Description of project sites: Stanford is in central Montana, is dryland prairie, with grain, hay, and cattle operations that are generally medium to large by Montana standards.  The project site has an elevation of 4073 feet, and average annual precipitation of 15.10 inches.  Plant establishment is dependent on residual moisture from winter plus spring and summer rainfall.  Soil pH is typically somewhat above 7.  The Marion and Kila sites are in northwest Montana, in heavily timbered areas with valley meadow bottoms that support hay and pasture.  The Marion site has an elevation of 3528 feet, and average annual precipitation of 18.78 inches.  The planting at this site will be irrigated; no other sites will be irrigated.  The Kila site has an elevation of 3183 feet, and average annual precipitation of 15.31 inches.  The average maximum temperatures for Stanford, Kila, and Marion are 56.6, 55.9, and 54.5 degrees F.  These temperatures plus the fact that Stanford is considerably windier implies that both evaporation and transpiration are greater than the other two sites.  Both the Marion and Kila sites have year-round streams that are used for irrigation and cattle.  Soil pH ranges from 6 to slightly above 7.  Drought conditions prevailed throughout Montana in 2021, which resulted in all counties designated for disaster relief.

Planting: Ranchers at all locations will prepare the ground and plant seed with practices and equipment they have used for many years during April and May, 2022.  The ground preparation and seeding is based on experiential knowledge, both personal and acquired from others, and has been judged successful for past plantings, provided there are no extreme weather events or other anomalies.

Sampling design and organization of results: Sampling with be done at three different times (early summer and early fall, 2022, and early summer, 2023), with a square quadrat having 40 inch sides, divided into 100 4 by 4 inch squares, with the sample locations at the 5 points of a "W" in the planted area, and sides of square quadrat oriented with the four directions.  Sample locations will be semi-permanently marked so that samples at all three dates are taken at the same locations.  Only presence in each 4 by 4 square will be recorded and then converted to a frequency percentage, and will also be divided by 11.11 (number of sq. ft. in a 40"x40" square) to obtain number of plants per square foot.  Since only presence is recorded, this will lead to a conservative estimate of frequency and number/sq. ft.  Rather than assign a certain value as a breakpoint between successful and unsuccessful, such as 21% in FNC09-753, we will provide three frequency categories: Poor (< 11%, 0-0.98 plants/sq. ft.), Fair (11-20%, 0.99-1.88 plants/sq. ft.), Good (>20%, at least 1.89 plants/sq. ft.).  Good thus corresponds to Successful in FNC09-753.  Expressing results as number of plants per square foot does permit statistical analysis by means of a t-test, which means that sample means can be tested against above interval endpoints.  However, presenting results by means of bar graphs with descriptive captions (including statistical results) and legends is thought to be more useful for ranchers, so this along with a narrative will be a primary focus in tours, presentation, and final report.  In addition, ranchers will report how they prepared the ground for seeding as well as the seeding rates they used along with seeding dates.

Education: At the Stanford site, dissemination of results (in October, 2023) will be by means of a tour of the project site, with guests provided a hard copy of the results, along with an oral presentation by the rancher-owner.  At the Marion site, dissemination of results (in September, 2023) will be by means of a tour of the project site, with guests provided a hard copy of the results, along with an oral presentation by the rancher-owner.  During November, 2023, at the Lake County Extension Office in Ronan, dissemination of results will include pictures and short videos taken at the times sampling occurred at Marion and Kila, along with presentation of results at all three locations, with guests provided a hard copy of the results.  We want to reach as large of an audience for the tours and presentation as possible.  To this end, we will notify and invite guests in several ways (see details in educational plan below).



Research results and discussion:

Pleasant Valley (Marion) Location, some irrigation

10 acres seeded to Shoshone sainfoin and Potomac orchardgrass at approximately 25 lbs/acre for sainfoin and 5 lbs/acre for orchardgrass

For 5 randomly chosen samples, there were 2.088 sainfoin plants per square foot on 8/17/22.  In 2023, there was a grasshopper infestation, and almost no sainfoin plants were observed in fall of 2023.

Kila Location, no irrigation

7 acres seeded to Shoshone sainfoin and Potomac orchardgrass at approximately 25 lbs/acre for sainfoin and 5 lbs/acre for orchardgrass

For 5 randomly chosen samples, there were 1.53 sainfoin plants per square foot on 8/16/22.

3 acres seeded to birdsfoot trefoil and Potomac orchardgrass at approximately 6 lbs/acre for birdsfoot trefoil and 5 lbs/acre for orchardgrass

For 5 randomly chosen samples, there were 1.854 birdsfoot trefoil plants per square foot on 8/17/22.

Stanford Location, no irrigation

No seeding was done at this location in 2022 due to drought conditions.  Seeding was done in spring of 2023, but similar to the Marion location, there was a grasshopper infestation, and no sainfoin plants were observed in early fall of 2023.



MODIFICATIONS: Due to the absence of sainfoin plants in fall of 2023 at both Marion and Stanford, believed due to a grasshopper infestation at both locations, a 1-year no cost extension was requested and approved.

Marion Location: About half of the 10 acres were reseeded to sainfoin in spring of 2024 with a no till drill.  This reseeding was deemed unsuccessful since only a few sainfoin plants were observed in fall of 2024.

Stanford Location: The grasshopper infestation remained at Stanford through summer of 2024.  It was reseeded to sainfoin in fall of 2024, but no sample results exist as of this time.  No conclusion regarding success or failure can be drawn at this time.

Kila Location: Sampling was continued in 2023 and 2024.  On 9/28/23 for the sainfoin seeding, there were 2.45 plants per square foot and on 11/17/24, there were 0.85 plants per square foot.  On 9/28/23 for the birdsfoot seeding, there were 3.02 plants per square foot and on 11/18/24, there were 0.61 plants per square foot.

Participation Summary
1 Producers participating in research

Research Outcomes

Recommendations for sustainable agricultural production and future research:

In 2022, planting objectives were met in the Pleasant Valley and Kila locations, but not the Stanford location.  The Stanford location was so dry that the Stanford rancher, Jess Alger, decided not to plant because he believed, based on experience, that germination would be low, and of those seeds that did germinate, seedling survival would also be low.  There is no irrigation at the Stanford location.  Moisture levels at the Pleasant Valley and Kila locations were deemed acceptable, primarily due to spring rains.  In Pleasant Valley, sampling at 5 randomly selected locations was done on 8/17/22, on approximately 10 acres that was seeded to Shoshone sainfoin and Potomac orchardgrass.  The average number of sainfoin plants per square foot was 2.088.  There was a small amount of irrigation available at this location.  At the Kila location, sampling at 5 randomly selected locations on approximately 7 acres seeded to Shoshone sainfoin and Potomac orchardgrass was done on 8/16/22.  The average number of sainfoin plants per square foot was 1.53.  Also at the Kila location, sampling at 5 randomly selected locations on approximately 3 acres seeded to birdsfoot trefoil and Potomac orchardgrass was done on 8/17/22.  The average number of birdsfoot trefoil plants per square foot was 1.854.  These two acreages are adjacent.  No irrigation was available at Kila.

We want to see what the second year of these plantings looks like before we make any recommendations.  Right now, we would view the results as successful, but it's possible that these plantings will not overwinter well.  And even if they do overwinter well, the forage production may not be substantial enough to be viewed as successful.  We will be able to assess both of these points by the end of this summer.  And finally, we intend to graze these pastures sometime in summer, so we will also have some visual, qualitative, results regarding grazing.

On 9/4/23 at Pleasant Valley, there were 10 sampling locations with an average of 0.117 sainfoin plants per square foot, which is a huge drop from the 2.088 approximately a year earlier.  On 9/28/23 at the Kila location, there were 5 sampling locations in the sainfoin planting with an average of 2.45 plants per square foot, which is an increase of 0.92 plants per square foot from 2022.  On the same date at the Kila location, there were 5 sampling locations in the birdsfoot trefoil planting with an average of 3.02 plants per square foot, which is an increase of 1.116 plants per square foot from 2022.  At the Stanford location on 10/3/23, the Stanford rancher, Jess Alger, and the PI, Ronald Wade, were unable to find any sainfoin plants.  Jess Alger reported that the spring/2023 seeding did germinate and had an adequate number of small sainfoin plants a few weeks later.  Grass plants at all three locations were adequate; it is only the absence of legumes at Pleasant Valley and Stanford along with an adequate presence of legumes at Kila that is noteworthy.

Although it was not a part of the grant proposal, the PI collected soil samples and had a Haney soil test performed by RegenAgLab.  From the analysis reports and also a discussion with a staff member, we do not see any soil differences that would account for the legume die-off at two locations and the continuing presence of legumes at the third location.   However, Ryan Wade at Pleasant Valley and Jess Alger at Stanford both reported major grasshopper infestations at these locations, while Ronald Wade at Kila reported a few grasshoppers, but nothing that could be called an infestation.  At this point, we believe that grasshopper infestations probably account for the legume die-off at Pleasant Valley and Stanford.

Assuming adequate moisture, Ryan Wade at Pleasant Valley and Jess Alger at Stanford will replant sainfoin in spring/2024.  The PI, Ronald Wade, will sample both these locations in June/2023, which is prior to the normal later time of an infestation, when these do occur.



MODIFICATIONS:  As noted above, replanting was done in spring/2024 at Pleasant Valley with a no-till drill.  That is, the previously seeded pasture was not plowed again since the grass seeding was deemed successful.  When sampled in early fall/2024, almost no sainfoin plants were found.  The conclusion is that it is unlikely to be able to establish sainfoin at this location in a no-till situation without prior plowing of the soil.

At the Stanford location, grasshoppers were very abundant in spring/2024, so replanting was not done at this time.  Instead, sainfoin planting was done in fall/2024, but no sampling has occurred as of this time.  Therefore, no conclusion can be drawn as to success or failure at this location.

At the Kila location, sampling that showed good numbers of both sainfoin and birdsfoot trefoil in 2023 leads to the conclusion that both legumes,  planted in spring of 2022, overwintered successfully from the winter of 2022-2023.  Therefore, the conclusion is that both legumes can be established successfully, provided there is prior plowing of the soil, and can overwinter successfully.  Based on the results at Marion and Stanford, it must also be concluded that young sainfoin plants in their first year are very susceptible to grasshopper infestations.  As noted above, sample numbers of both sainfoin and birdsfoot trefoil at the Kila location dropped to a very low number by the fall of 2024.  However, cattle numbers grazing this location were much higher in 2024 than in either 2022 or 2023, which leads to the conclusion that cattle numbers must be managed so as to not adversely impact the legumes.  An observation of interest is that the Canada thistle in association with these legumes was also adversely impacted, presumably by cattle eating the young thistle plants while they grazed the nearby desirable legumes.  The total of 10 acres, 7 of sainfoin and 3 of birdsfoot, is part of a much larger pasture of only grass.  During the three years of this study, 2022-2024, the entire pasture was not set up for rotational grazing.  It is now set up for rotational grazing for 2025, and it will be grazed in this manner going forward.  Graphs that show legume numbers and cattle numbers during 2022-2024 are shown in the Education and Outreach section below.

Part of the process of determining what works in establishing a legume pasture for grazing is also finding out what doesn't work.  The 'failures' noted above are examples of the latter.

Education and Outreach

1 Curricula, factsheets or educational tools
1 Webinars / talks / presentations

Participation Summary:

45 Farmers participated
Education and outreach methods and analyses:

Education and outreach activities in our proposal were planned for late summer and fall of 2023, and early spring of 2024.  So, we have not yet done these.

MODIFICATIONS:  On 2/5/25, I received an email stating that MSU requests all awardees pause any further spending.  I cancelled all planned education and outreach activities, and replaced them with one education and outreach activity in Kalispell on 4/5/2025.  This activity occurred in conjunction with a meeting of the local chapter of Montana Farmers Union and Glacier Processing Coop, and it was completed.

Education and outreach results:

See above under education and outreach methods and analyses.

Establishing_a_legume_pasture

Public outreach presentation

The above file, Establishing a legume pasture (click on the filename above to access the presentation), which is a series of slides including graphs of legume numbers and cattle numbers (AUMs or animal unit months), was presented on April 5, 2025 by Lisa Wade at a joint meeting of the local chapter of Montana Farmers Union and Glacier Processing Coop.  Two pictures taken during the presentation are included above.  The slide presentation and graphs were created by Pete Wade using LaTeX.

2 Farmers intend/plan to change their practice(s)

Education and Outreach Outcomes

Recommendations for education and outreach:

There have not yet been any education and outreach activities.  In our proposal, these were planned for late summer and fall of 2023, and early spring of 2024.

We have been granted a one-year no cost extension due to the research results that are reported above for 2023.  So, there have not been any education and outreach activities to this point.



In the Q & A following the slide presentation 'Establishing a legume pasture', there were 8-10 questions from audience members.  Every one of the questions related to the two graphs.  Examples: One question asked for the exact seeding rate, which was given in the caption information, but was a little too small for the questioner to read from a seat near the rear of the room.  Another question asked if the Canada thistle damage was thought to be more due to dry conditions or cattle grazing.  My response was grazing pressure because thistle plants did well in nearby areas that had not been grazed.

My conclusion in regard to recommendations, in accordance with the saying that a picture is worth a thousand words, is that results that are presented in a visual format such as graphs, are found to be helpful, interesting, and informative by many people in an audience.  I went to some trouble to make the graphs simple (basic line graphs) and visually appealing (I used several colors), but also contain specific information (all three axes were completely labelled plus legend and caption information was included).

8 Producers reported gaining knowledge, attitude, skills and/or awareness as a result of the project
Non-producer stakeholders reported changes in knowledge, attitudes, skills and/or awareness as a result of project outreach
8 General public
Key changes:
  • See specific questions asked by audience members above.
